PLANQ N20 Art Specifications

Item
Details
Basic information Model No.N20 Art
Colour Silver Grey
Material Metal
Unit size 360*242*20 mm
Net weight 1886g
Packing list Laptop*1
power adapter*1
user’s manual *1
Mouse*1
Mouse Pad*1
CPU & Operation system CPU Intel Core i7-13620H
Cores & Threads 10 Cores 16 Threads(6P4E)
CPU speed Efficient-core Max Turbo Frequency:3.60 GHz
Performance-core Max Turbo Frequency:4.90GHz
Lithography Intel 7
Smart cache 24 MB Intel® Smart Cache
Operation system Windows 11
Power consumption 35W-115W, default 45 W
Graphic card Model No. Intel® UHD Graphics for 13th Gen Intel® Processors
Graphics Max Dynamic Frequency 1.50 GHz
Display Display size 16″
Display resolution 2560*1600
Display rate 16：10
Display type QHD
Gamut 100% sRGB
Refresh rate 165Hz
Matte or glossy Matte
View angle 170°(horizontal) / 170°(Vertical) (CR>10,typical)
Uni-body No
Opening angle 135 degree
Brightness 400cd/㎡（typical）
Memory Memory size 32G
Memory ports SO-DIMM*2
Memory type DDR4 2666Mhz
Max size 64GB
Hard disk Default  size&sype 1TB NVME
Default  HDD speed/SSD speed 8Gbps
Ports NVME m.2 2280*2
Extenal ports Yes
Extenal ports type NVME*1
Interface NVME m.2 2280*1
Max size 4TB
Connection ports USB2.0 USB2.0*1
USB3.0 USB3.0*2
USB3.1 N/A
USB3.2 N/A
HDMI HDMI*1
TYPE-C TYPE-C*2,one full function,another charging only
Thunderbolt N/A
Audio Ø3.5mm *1
RJ45 RJ45*1
Charge port size 4.8mm/1.7mm
Communications BT BT5.0
LAN Supports 10/100/1000M sec
WIFI WIFI6.0  IEEE 802.11ax
In-put devices Keyboard US Keyboard
Keyboard light colour White light backlit
Keyboard light software N/A
Touch pad Clickpad 125*85mm
Audio Speaker 2 build-in speakers
Dolby support N/A
Bass Not support
Build-in microphone Analog Microphone support
Power supply Battery capacity 11.55V/5000mAh, 57.75Wh
Removeable or not not removeable
Power adaptor Input: 100~240V AC, 50-60Hz/Output: 19V/3.42A,65W
